Agilent Technologies N5242A - Information in this Chapter; Chapter Seven At-A-Glance

7-2 Service Guide N5242-90001
Repair and Replacement Procedures PNA Series Microwave Network Analyzers
Information in This Chapter N5242A
Information in This Chapter
This chapter contains procedures for removing and replacing the major assemblies of your
Agilent Technologies PNA series microwave network analyzer.
Chapter Seven at-a-Glance
Section Title Summary of Content Start Page
Personal Safety Warnings Warnings and cautions pertaining to personal
safety.
Page 7-3
Electrostatic Discharge (ESD)
Protection
Information pertaining to ESD protection. Page 7-3
Table of Removal and
Replacement Procedures
A table of removal and replacement
procedures and the corresponding page
number where they are located.
Page 7-4
Removal and Replacement
Procedures
The actual procedures for removing and
replacing the major assemblies in your
analyzer.
The procedures occur in assembly reference
designator numerical order.
See Table 7-1
on page 7-4
for specific
procedures.
Post-Repair Procedures A table for the proper tests, verifications, and
adjustments to perform on your analyzer after
repair.
Page 7-64
