6-22 Service Guide N5242-90001
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings N5242A
Bottom Ribbon Cables and Wire Harnesses, Standard 2-Port
Configuration, Option 200
Reference
Designator
Type
a
a. nR = n wires in a ribbon (flat) cable; nW = n wires in a wire harness
Part Number Description
➀
4W N5242-60002 A19 test set motherboard J3 to A33 reference mixer switch
➁
3W N5242-60009 A19 test set motherboard J221 to port 1 LED board J1
➂
10R N5242-60005 Rear-panel PWR I/O to A19 test set motherboard J301
➃
16R N5242-60006 A19 test set motherboard J212 to A23 mixer brick (1)
➄
3W N5242-60009 A19 test set motherboard J222 to port 2 LED board J1
➅
24R N5242-60011 A19 test set motherboard J209 to A21 HMA26.5
➆
100R N5242-60004
A14 system motherboard J1 to A19 test set motherboard J1 to
A20 IF multiplexer board J1
➇
36R 8121-0834 Rear-panel HANDLER I/O to A19 test set motherboard J400
