6-34 Service Guide N5242-90001
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings N5242A
Bottom RF Cables, 2-Port, Option 224 without Option 029
Reference
Designator
Type
a
Part Number Qty Description
W3 SR N5242-20091 1 A5 source (1) to W95
W5 SR N5242-20091 1 A8 source (2) to W101
W7 SR N5242-20092 1 A8 source (2) to W115
W9 SR N5242-20092 1 A5 source (1) to W109
W13 SR N5242-20011 1 A25 port 1 bridge to A33 reference mixer switch
W25 SR N5242-20048 1 A28 port 2 bridge to front-panel REF 2 SOURCE OUT
W30 SR E8356-20072 6 Front panel jumper
W35 SR N5242-20043 1
A33 reference mixer switch to front-panel REF 1 SOURCE OUT
W36 SR N5242-20042 1 REF 1 RCVR R1 IN to A33 reference mixer switch
W37 SR N5242-20009 1 A33 reference mixer switch to A23 mixer brick (R1)
W40 SR N5242-20049 1 REF 2 RCVR R2 IN to A23 mixer brick (R2)
W41 SR N5242-20110 1 A11 13.5 GHz synthesizer to A21 HMA26.5
W45 SR N5242-20093 1 A8 source (1) to W46
W46 SR N5242-20090 1 W46 to rear-panel EXT TSET DRIVE RF OUT (J6)
W47 SR N5242-20089 1 A23 mixer brick to EXT TSET DRIVE LO OUT (J5)
W51 F N5242-60017 1 A23 mixer brick (A) to A20 IF multiplexer (P1)
W54 F N5242-60018 1 A23 mixer brick (B) to A20 IF multiplexer (P201)
W59 F N5242-60012 1 A20 IF multiplexer (P3) to A12 SPAM (J1)
W60 F N5242-60013 1 A20 IF multiplexer (P203) to A12 SPAM (J2)
W61 F N5242-60014 1 A20 IF multiplexer (P403) to A12 SPAM (J4)
W62 F N5242-60015 1 A20 IF multiplexer (P603) to A12 SPAM (J5)
W63 F N5242-60016 1 A20 IF multiplexer (P803) to A12 SPAM (J6)
W64 F N5242-60025 1 A23 mixer brick (R1) to A20 IF multiplexer (P601)
W65 F N5242-60026 1 A23 mixer brick (R2) to A20 IF multiplexer (P801)
W67 SR N5242-20106 1 A47 SRC 2 OUT 1 switch to front-panel SRC 2 OUT 1
W68 SR N5242-20107 1 W7 to SRC 2 OUT 2
W70 SR N5242-20123 1 A21 HMA26.5 to A23 mixer brick
W71 SR N5242-20005 1 A25 port 1 bridge to A34 port 1 source attenuator
W72 SR N5242-20038 1
A34 port 1 source attenuator to front-panel Port 1 SOURCE OUT
W73 SR N5242-20039 1 Port 1 CPLR THRU to A38 port 1 bias tee
W83 SR N5242-20002 1 A28 port 2 bridge to A37 port 2 source attenuator
W84 SR N5242-20046 1
A37 port 2 source attenuator to front-panel Port 2 SOURCE OUT
W85 SR N5242-20045 1 Port 2 CPLR THRU to A41 port 2 bias tee
W87 SR N5242-20041 1 Port 1 RCVR A IN to A42 port 1 receiver attenuator
W88 SR N5242-20010 1 A42 port 1 receiver attenuator to A23 mixer brick (A)
W93 SR N5242-20047 1 Port 2 RCVR B IN to A45 port 2 receiver attenuator
W94 SR N5242-20016 1 A45 port 2 receiver attenuator to A23 mixer brick (B)
W95 SR N5242-20020 1 W3 to A46 port 1 source bypass switch
W96 SR N5242-20007 1 A46 port 1 source bypass switch to A25 port 1 bridge
W97 SR N5242-20086 1 A46 port 1 source bypass switch to PORT 1 SW SRC OUT (J11)
W98 SR N5242-20087 1 Rear-panel PORT 1 COMB THRU IN (J10) to A50 combiner
W99 SR N5242-20088 1 Rear-panel PORT 1 COMB ARM IN (J9) to A50 combiner
W100 SR N5242-20008 1 A50 combiner to A46 port 1 source bypass switch
W101 SR N5242-20017 1 W5 to A47 SRC 2 source bypass switch
W103 SR N5242-20081 1 A47 SRC 2 source bypass switch to SRC 2 SW SRC OUT (J8)
W104 SR N5242-20080 1
Rear-panel PORT 3 SW TSET IN (J7) to A47 SRC 2 source bypass switch
W109 SR N5242-20019 1 W9 to A49 port 2 source bypass switch
W110 SR N5242-20004 1 A4 port 2 source bypass switch to A28 port 2 bridge
W111 SR N5242-20084 1 A49 port 2 source bypass switch to PORT 2 SW SRC OUT (J2)
W112 SR N5242-20085 1
Rear-panel PORT 2 SW TSET IN (J1) to A49 port 2 source bypass switch
W113 SR E8356-20072 3 Rear panel jumper
W115 SR N5242-20113 1 A29 port 1 coupler to front-panel Port 1 CPLR ARM
