Appendix A Specifications
122 Series N6700 User’s Guide
Agilent Models N6751A/N6752A and N6761A/N6762A (continued)
N6751A / N6752A N6761A / N6762A
Maximum Up-programming Time with full resistive load:
(time f
rom 10% to 90% of total voltage excursion)
Voltage setting from 0 V to 10 V 0.2 ms 0.6 ms
Voltage setting from 0 V to 50 V 1.5 ms 2.2 ms
Maximum Up-programming Settling Time with full resistive load:
(time from start of voltage change to within 50mV of final value)
Voltage setting from 0 V to 10 V 0.5 ms 0.9 ms
Voltage setting from 0 V to 50 V 4.0 ms 4.0 ms
Maximum Down-programming Time with no load:
(time f
rom start of voltage change to output voltage < 0.5 V)
Voltage setting from 10 V to 0 V 0.3 ms 0.3 ms
Voltage setting from 50 V to 0 V 1.3 ms 1.3 ms
Maximum Down-programming Settling Time with no load:
(time f
rom start of voltage change to output voltage within 50mV of final value)
Voltage setting from 10 V to 0 V 0.45 ms 0.45 ms
Voltage setting from 50 V to 0 V 1.4 ms 1.4 ms
Down-programming Time with 1000 µF load:
NOTE 2
(time f
rom start of voltage change to output voltage < 0.5 V)
Voltage setting from 10 V to 0 V 2.1 ms 4.5 ms
Voltage setting from 50 V to 0 V 11 ms 23 ms
Down-programming Capability:
Continuous power 7 W 7 W
Peak current 7 A 3.8 A
Remote Sense Capability:
Outputs can maintain specifications with up to a 1-volt
drop per load lead.
Series and Parallel Operation:
Identically rated outputs can be operated directly in
parallel or can be connected for straight series
operation. Auto-series and auto-parallel operation is not
available.
Load Cross Regulation:
Voltage, from no load to full load 1 mV 0.5 mV
Current, from no load to full load 1 mA
5 µA
2
Modules can discharge a 1000µF capacitor from 50V to 0V at a rate of 4 times/second.
