Service Appendix D
Series N6700 User’s Guide 183
Parts List and Parts Location
The following table documents the replaceable parts assembles. The
diagrams show the location of the parts.
Reference
Designator
N6700B
Part number
N6700A
Part number
Description
Electrical Assemblies
A1 N6700-69001 N6700-69001 A1 Front Panel PCA (tested)
A2 0950-4655 0950-4494 A2 Bulk Supply
A3 5065-6981 5065-6981 A3 Backplane PCA
A4 N6700-60101 5065-7008 A4 Carrier/Bias PCA (tested)
A5 N6700-60102 5065-7010 A5 Interface PCA (tested)
Individual Parts
1 5002-2817 5002-2805 Chassis frame
2 5002-2808 5002-2808 Front frame
3 1390-1079 1390-1079 Handles
4 N6700-40001 N6700-40001 Keypad
5 2090-0886 2090-0886 Display
6 4040-2556 4040-2556 Window
7 N6700-00001 N6700-00001 Front panel
8 3101-4019 3101-4019 Line switch
9 5185-1358 5185-1358 Cable, bulk supply to ground
10 5185-1357 5185-1357 Cable, bulk supply to switch
11 5185-1362 5185-1362 Cable, DC power
12 5185-1354 5185-1354 Ribbon cable, to front panel
13 5185-1382 5185-1353 Ribbon cable, to backplane
14 5185-1352 5185-1352 Insulator, under backplane
15 5185-1384 N/A Bias cable assembly
16 5185-1397 5185-1355 AC cable with socket
17 1510-0038 1510-0044 Binding post
18 E5810-61605 E5810-61605 GPIB connector with cable
19 1253-6408 1253-5830 Digital plug
Covers and Labels
5002-2809 5002-2809 Bulk supply cover
5002-2810 5002-2810 Blower cover
5002-2807 5002-2807 Interface cover
N6700-80006 N6700-80001 Front/Rear/Interface labels
5185-1387 5185-1387 Blower cover label (caution)
