Appendix A Specifications
118 Series N6700 User’s Guide
Performance Specifications
Agilent Models N6751A/N6752A and N6761A/N6762A
N6751A / N6752A N6761A / N6762A
DC Output Ratings:
Voltage 50 V 50 V
Current (derated 1% per °C above 40°C) 5 A / 10A 1.5 A / 3 A
Power 50 W / 100 W 50 W / 100 W
Output Ripple and Noise (PARD):
(from 20 Hz – 20 MHz)
CV peak-to-peak
NOTE 1
6 mV 6 mV
CV rms 1 mV 1 mV
Load Effect (Regulation)
(for any output load change, with a maximum load-lead drop of 1V/lead)
Voltage 2 mV 0.5 mV
Current (@ 0 - 7 V)
(@ 0 - 50 V)
2 mA
2 mA
30 µA
NOTE 2
65 µA
Source Effect (Regulation):
Voltage 1 mV 0.5 mV
Current 1 mA 30 µA
Programming Accuracy:
(@ 23 °C ±5 °C after 30 min. warm-up. Applies from min. to max. programming range)
Voltage high range 0.06% + 19 mV 0.016% + 6 mV
Voltage low range (≤ 5.5 V) N/A 0.016% + 1.5 mV
Current high range 0.1% + 20 mA 0.04% + 200 µA
Current low range (≤ 100 mA, @ 0 - 7 V)
(≤ 100 mA, @ 0 - 50 V)
N/A
N/A
0.04% + 15 µA
0.04% + 55 µA
Measurement Accuracy:
(at 23 °C ±5 °C)
Voltage high range 0.05% + 20 mV 0.016% + 6 mV
Voltage low range (≤ 5.5 V) N/A 0.016% + 1.5 mV
Current high range 0.1% + 4 mA 0.04% + 160 µA
Current low range (≤ 100 mA, @ 0 - 7 V)
(≤ 100 mA, @ 0 - 50 V)
N/A
N/A
0.03% + 15 µA
NOTE 2
0.03% + 55 µA
Load Transient Recovery Time:
(time to recover to within the settling band following a load change
- from 60% to 100% and from 100% to 60% of full load for models N6751A & N6761A
- from 50% to 100% and from 100% to 50% of full load for models N6752A &N6762A.)
Voltage settling band ± 75 mV
NOTE 3
± 75 mV
Time < 100 µs < 100 µs
1
For typical values, refer to Supplemental Characteristics.
2
Applies when measuring 4096 data points (SENSe:SWEep:POINts = 4096).
3
Settling band is ±125 mV for Model N6752A when relay option 761 is installed.
