Specifications Appendix A
Series N6700 User’s Guide 121
Supplemental Characteristics
Agilent Models N6751A/N6752A and N6761A/N6762A
N6751A / N6752A N6761A / N6762A
Programming Ranges:
Voltage high range 20 mV – 51 V 15 mV – 51 V
Voltage low range (≤ 5.5 V)
N/A 12 mV – 5.5 V
Current high range
10 mA - 5.1A/10 mA- 10.2A 1 mA - 1.53 A/1 mA - 3.06 A
Current low range (≤ 0.1 A)
N/A
0.1 mA – 0.1 A
NOTE 1
Programming Resolution:
Voltage high range 3.5 mV
880 µV
Voltage low range (≤ 5.5 V)
N/A
90 µV
Current high range 3.25 mA
60 µA
Current low range (≤ 0.1 A)
N/A
2 µA
Measurement Resolution:
Voltage high range 1.8 mV
440 µV
Voltage low range (≤ 5.5 V)
N/A
44 µV
Current high range
410 µA 30 µA
Current low range (≤ 0.1 A)
N/A
1 µA
Programming Temperature Coefficient per °C:
Voltage high range
18 ppm + 160 µV 18 ppm + 140 µV
Voltage low range (≤ 5.5 V)
N/A
40 ppm + 70 µV
Current high range
100 ppm + 45 µA 33 ppm + 10 µA
Current low range (≤ 0.1 A)
N/A
60 ppm + 1.5 µA
Measurement Temperature Coefficient per °C:
Voltage high range
25 ppm + 35 µV 23 ppm + 40 µV
Voltage low range (≤ 5.5 V)
N/A
30 ppm + 40 µV
Current high range
60 ppm + 3 µA 40 ppm + 0.3 µA
Current low range (≤ 0.1 A)
N/A
50 ppm + 0.3 µA
Output Ripple and Noise (PARD):
CV peak-to-peak (typical value) 4 mV 4 mV
CC rms: 2 mA 2 mA
Common Mode Noise:
(from 20 Hz – 20 MHz; from either output to chassis)
rms
500 µA 500 µA
peak-to-peak < 2 mA < 2 mA
Over-voltage Protection:
Accuracy 0.25% + 250 mV 0.25% + 250 mV
Maximum setting 55 V 55 V
Response time
50 µs from occurrence of over-voltage
condition to start of output shutdown
1
If you are operating the unit below 255 µA in constant current mode, the output may
become unregulated with the following load conditions: The load resistance is <175 mΩ and
the load inductance is >20 µH. If this occurs, an UNRegulated flag will be generated and the
output current may rise above the programmed value but will remain less than 255 µA.
