Series N6700 User’s Guide 15
2
Installation
General Information..........................................................................................16
Inspecting the Unit ...........................................................................................17
Installing the Unit.............................................................................................. 17
Connecting the Line Cord ................................................................................ 19
Connecting the Outputs................................................................................... 20
Remote Sense Connections ............................................................................ 24
Parallel Connections......................................................................................... 25
Series Connections........................................................................................... 26
This chapter describes how to install your power system. It discusses
installation, rack mounting, and line cord connections.
This chapter discusses how to connect your load to the output
terminals. It discusses what you need to know about wire sizes and
how to compensate for voltage drops in the load leads. It also
discusses various loads configurations and how to connect the output
terminals in series and parallel.
Before installing the instrument, check the list under “Items
Supplied” and verify that you have received these items with your
instrument. If anything is missing, please contact your nearest
Agilent Sales and Support Office.
