Agilent Technologies N6751A User Manual

2 Installation
16 Series N6700 User’s Guide
General Information
Models
Agilent Model Description
N6700A / N6700B MPS Mainframe - without DC Power Modules
N6751A / N6752A 50 W / 100 W High-Performance Autoranging DC Power Module
N6761A / N6762A 50 W / 100 W Precision DC Power Module
N6731B / N6741B 50 W / 100 W 5 V DC Power Module
N6732B / N6742B 50 W / 100 W 8 V DC Power Module
N6733B / N6743B 50 W / 100 W 20 V DC Power Module
N6734B / N6744B 50 W / 100 W 35 V DC Power Module
N6735B / N6745B 50 W / 100 W 60 V DC Power Module
N6736B / N6746B 50 W / 100 W 100 V DC Power Module
N6731A 50 W 5 V DC Power Module
N6732A / N6742A 50 W / 80 W 8 V DC Power Module
N6733A / N6743A 50 W / 100 W 20 V DC Power Module
N6734A / N6744A 50 W / 100 W 35 V DC Power Module
N6735A / N6745A 40 W / 80 W 50 V DC Power Module
N6708A Filler Module Kit (includes 3 filler modules)
N6709A Rack Mount Kit (also available as Option 908)
Items Supplied
Item Description Agilent Part Number
Power Cord A power cord appropriate for your location. Call Agilent Sales & Support Office
Output Connector A 4-pin connector for connecting power and remote sense
leads.
1253-5826 or
1253-6211 (model N6741B only)
Sense Jumpers Two jumpers per module for local sensing at the output
connector.
8120-8821 or
0360-2935 (model N6741B only)
Digital Connector An 8-pin connector for connecting signal lines to the digital
port.
(N6700A mainframes use a 4-pin connector.)
1253-6408 (8-pin) or
1253-5830 (4-pin)
Manual Set Contains User’s Guide and Product Reference CD-ROM. 5969-2916
Certificate of Calibration A certificate of calibration referenced to the serial number. N/A
Automation-Ready CD-ROM Contains Agilent IO Libraries Suite. E2094N
Filler Modules Provided if there are less than four power modules installed. N6708A
Options
Option Description
054 High-speed Test Extensions. Includes digitized output measurements and output list capability.
Available for Agilent Models N6751A/N6752A. Included with Agilent Models N6761A/N6762A.
761 Output relays. Includes 2 - DPDT galvanic-disconnect relays. Disconnects both output and sense
terminals. Available for all Agilent Models.
908 Rack Mount Kit for mounting in a 19-inch EIA rack cabinet. Also available as Model N6709A.
