Appendix A Specifications
120 Series N6700 User’s Guide
Agilent Models N6731B - N6736B and N6741B - N6746B
N6731B/
N6741B
N6732B/
N6742B
N6733B/
N6743B
N6734B/
N6744B
N6735B/
N6745B
N6736B/
N6746B
DC Output Ratings:
Voltage 5 V 8 V 20 V 35 V 60 V 100 V
Current
NOTE 1
10 A / 20 A 6.25 A / 12.5 A 2.5 A / 5 A 1.5 A / 3 A 0.8 A / 1.6 A 0.5 A / 1 A
Power 50 W / 100 W 50 W / 100 W 50 W / 100 W 52.5W / 105W 50 W / 100 W 50 W / 100 W
Output Ripple and Noise (PARD):
(from 20 Hz – 20 MHz)
CV peak-to- peak 10 mV / 11mV 12 mV 14 mV 15 mV 25 mV 30 mV
CV rms 2 mV 2 mV 3 mV 5 mV 9 mV 18 mV
Load Effect (Regulation):
(with output change from no load to full load, up to a maximum load-lead drop of 1V/lead)
Voltage 5 mV 6 mV 9 mV 11 mV 13 mV / 16 mV 20 mV / 30 mV
Current 2 mA 2 mA 2 mA 2 mA 2 mA 2 mA
Source Effect (Regulation):
Voltage 1 mV 2 mV 2 mV 4 mV 6 mV 10 mV
Current 1 mA 1 mA 1 mA 1 mA 1 mA 1 mA
Programming Accuracy:
(@ 23 °C ±5 °C after 30 minute warm-up. Applies from minimum to maximum programming range)
Voltage 0.1% + 19 mV 0.1% + 19 mV 0.1% + 20 mV 0.1% + 35 mV 0.1% + 60 mV 0.1% +100 mV
Current
0.15% + 20 mA 0.15% + 20 mA 0.15% + 20 mA 0.15% + 20 mA 0.15% + 20 mA 0.15% + 10mA
Measurement Accuracy:
(at 23 °C ±5 °C)
Voltage 0.1% + 20 mV 0.1% + 20 mV 0.1% + 20 mV 0.1% + 35 mV 0.1% + 60 mV 0.1% +100 mV
Current 0.15% + 20 mA 0.15% + 10 mA 0.15% + 5 mA 0.15% + 4 mA 0.15% + 4 mA 0.15% + 2 mA
Load Transient Recovery Time:
(time to recover to within the settling band following a load change
from 50% to 100% and from 100% to 50% of full load.)
Voltage settling band ± 0.08V / 0.1 V ± 0.08V / 0.1 V ± 0.2 V / 0.3 V ± 0.2 V / 0.3 V ± 0.4 V / 0.5 V ± 0.5 V / 1.0 V
Time < 200 µs < 200 µs < 200 µs < 200 µs < 200 µs < 200 µs
1
Output current is derated 1% per °C above 40°C.
