Specifications Appendix A
Series N6700 User’s Guide 119
Agilent Models N6731A - N6735A and N6742A - N6745A
N6731A N6732A/N6742A N6733A/N6743A N6734A/N6744A N6735A/N6745A
DC Output Ratings:
Voltage 5 V 8 V 20 V 35 V 50 V
Current
NOTE 1
10 A 6.25 A / 10 A 2.5 A / 5 A 1.5 A / 3 A 0.8 A / 1.6 A
Power 50 W 50 W / 80 W 50 W / 100 W 52.5 W / 105 W 40 W / 80 W
Output Ripple and Noise (PARD):
(from 20 Hz – 20 MHz)
CV peak-to- peak 10 mV 12 mV 14 mV 15 mV 20 mV
CV rms 2 mV 2 mV 3 mV 5 mV 9 mV
Load Effect (Regulation):
(with output change from no load to full load, up to a maximum load-lead drop of 1V/lead)
Voltage 2 mV 2 mV 2 mV 4 mV 6 mV
Current 2 mA 2 mA 2 mA 2 mA 2 mA
Source Effect (Regulation):
Voltage 1 mV 2 mV 2 mV 4 mV 6 mV
Current
1 mA 1 mA 1 mA 1 mA 1 mA
Programming Accuracy:
(@ 23 °C ±5 °C after 30 minute warm-up. Applies from minimum to maximum programming range)
Voltage 0.1% + 19 mV 0.1% + 19 mV 0.1% + 20 mV 0.1% + 35 mV 0.1% + 60 mV
Current
0.15% + 20 mA 0.15% + 20 mA 0.15% + 20 mA 0.15% + 20 mA 0.15% + 20 mA
Measurement Accuracy:
(at 23 °C ±5 °C)
Voltage 0.1% + 20 mV 0.1% + 20 mV 0.1% + 20 mV 0.1% + 35 mV 0.1% + 60 mV
Current
0.15% + 20 mA 0.15% + 10 mA 0.15% + 5 mA 0.15% + 4 mA 0.15% + 4 mA
Load Transient Recovery Time:
(time to recover to within the settling band following a load change
from 50% to 100% and from 100% to 50% of full load.)
Voltage settling band ± 80mV ± 80mV ± 200mV ± 200mV ± 200mV
Time
< 200 µs < 200 µs < 200 µs < 200 µs < 200 µs
1
Output current is derated 1% per °C above 40°C.
