Verification and Calibration Appendix B
Series N6700 User’s Guide 139
Test Record Form – Agilent N6761A and N6762A
Agilent N6761A and N6762A Report No _______________ Date __________________
Description Model Minimum Specs. Results Maximum Specs.
Constant Voltage Tests
High Range Voltage Prog. & Readback
Minimum Voltage Vout
Front Panel Display Readback
High Voltage Vout
Front Panel Display Readback
Both
Both
Both
Both
+ 9 mV
Vout 6 mV
49.986 V
Vout 14 mV
__________
__________
__________
__________
+ 21 mV
Vout + 6 mV
50.014 V
Vout + 14 mV
Low Range Voltage Prog. & Readback
Low Voltage Vout
Front Panel Display Readback
Both
Both
5.4976 V
Vout 2.4 mV
__________
__________
5.5024 V
Vout + 2.4 mV
CV Load Effect
Both
0.5 mV
__________
+ 0.5 mV
CV Source Effect
Both
0.5 mV
__________
+ 0.5 mV
CV Ripple and Noise
peak-to-peak
rms
Both
Both
N/A
N/A
__________
__________
+ 6 mV
+ 1 mV
Transient Response
Voltage at 150 µs
Both
75 mV
__________
+ 75 mV
Constant Current Tests
High Range Current Prog. & Readback
Minimum Current Iout
Front Panel Display Readback
High Current Iout
Front Panel Display Readback
Both
Both
N6761A
N6762A
N6761A
N6762A
+ 0.8 mA
Iout 160 µA
1.4992 A
2.9986 A
Iout 0.76 mA
Iout 1.36 mA
__________
__________
__________
__________
__________
__________
+ 1.2 mA
Iout + 160 µA
1.5008 A
3.0014 A
Iout + 0.76 mA
Iout + 1.36 mA
Low Range Current Prog. & Readback
Low Current (Full Scale) Iout
Front Panel Display Readback
Both
Both
0.099945 A
Iout 45 µA
__________
__________
0.100055 A
Iout + 45 µA
CC Load Effect
Both
65 µA
__________
+ 65 µA
CC Source Effect
Both
30 µA
__________
+ 30 µA
Instrument Settings
Test Description N6761A N6762A.
Voltage Programming & Readback, Min Voltage 15 mV, 1.5 A 15 mV, 3 A
Voltage Programming & Readback, High Voltage 50 V, 1 A 50 V, 2 A
Voltage Programming & Readback, Low Voltage 5.5 V, 1.5 A 5.5 V, 3 A
CV Load Effect, Source Effect, Ripple and Noise 50 V, 1 A 50 V, 2 A
Transient Response 50 V, from 0.5 A to 1 A 50 V, from 1 A to 2 A
Current Programming & Readback, Min Current 1 mA, 50 V 1 mA, 50 V
Current Programming & Readback, High Current 1.5 A, 33 V 3 A, 33 V
Current Programming & Readback, Low Current 0.1 A, 50 V 0.1 A, 50 V
CC Load Effect, Source Effect, Ripple and Noise 1.5 A, 33 V 3 A, 33 V
