Using the Digital Port Appendix C
Series N6700 User’s Guide 167
Front Panel: SCPI Command:
Select System\DigPort, then
Pin<#> where # is the pin number.
Select Function, then either
Trigger In or Trigger Out.
Go back one level, select Polarity,
then either Positive or Negative.
To select the trigger output function
for pin 1:
DIG:PIN1:FUNC TOUT
To select the trigger input function for
pin 2:
DIG:PIN2:FUNC TINP
To select the trigger polarity:
DIG:PIN<#>:POL <pol>
Fault Output
Pins 1 and 2 can be configured as a fault-output pair. The polarity of
pin 1 can also be configured.
Front Panel: SCPI Command:
Select System\DigPort\Pin1.
Select Function, then Fault Out.
Go back one level, select Polarity,
then either Positive or Negative.
To configure the Fault function:
DIG:PIN1:FUNC FAUL
To select the fault output polarity:
DIG:PIN1:POL <pol>
Inhibit Input
Pin 3 can be configured as a remote inhibit input. The polarity of pin
3 can also be configured.
Front Panel: SCPI Command:
Select System\DigPort\Pin3.
Select Function, then Inhibit In.
Go back one level, select Polarity,
then either Positive or Negative.
To configure the Inhibit function:
DIG:PIN3:FUNC INH
To select the inhibit input polarity:
DIG:PIN3:POL <pol>
After you have configured pin 3 as the remote inhibit input, you must
also configure the operating mode of the inhibit signal. The inhibit
signal can be latched or live. When latched, the outputs will remain
disabled after an inhibit signal is received. When live, the outputs will
follow the state of the inhibit input. The Inhibit operating mode is
stored in non-volatile memory.
Front Panel: SCPI Command:
Select Protection/Inhibit.
Select either Latching or Live.
To disable Inhibit, select Off
To latch the Inhibit signal:
OUTP:INH:MODE LATC
To set the Inhibit signal live:
OUTP:INH:MODE LIVE
To disable the Inhibit signal:
OUTP:INH:MODE OFF
