Service Appendix D
Series N6700 User’s Guide 177
Overall Troubleshooting
Overall Troubleshooting Sheet 1
Turn on unit and observe the display. After a
few seconds it will display the Agilent logo and
the GPIB address. After self- test, it should
either display an error or go to metering mode.
Is the display
working?
Check that ribbon cable is properly inserted between
front panel board and carrier/bias board.
Perform carrier/bias assembly troubleshooting.
Perform front panel assembly troubleshooting.
No output on
all channels ?
YES
Check for 48V from A2 bulk supply.
Perform carrier/bias assembly troubleshooting.
Perform backplane assembly troubleshooting.
YES
Go to Sheet 2
NO
Is bulk supply
fan running?
NO
YES
YES
Check the line switch.
Check cables from AC plug to line switch and from line
switch to A2 bulk supply.
Check for 48V from A2 bulk supply.
NO
Start
Is there a
strange noise?
Check the fans on the output modules.
Troubleshoot carrier/bias assembly.
Check the fans on the A2 bulk supply.
YES
NO
NO
Selftest error?
Perform verification procedures in User's guide.
Calibrate the output if required.
Replace the output module.
YES
Does keypad
work?
Perform front panel troubleshooting.
Perform carrier/bias assembly troubleshooting.
Replace the keypad.
NO
To Next Page
