Quick Reference 1
Series N6700 User’s Guide 9
Remote voltage
sensing
Two remote sensing terminals are provided for each output. When shipped from the
factory, the remote sense jumpers are included in a separate bag. Refer to Chapter 2
for details.
Voltage
and current
measurements
All power modules can measure their own output voltage and current.
Voltage, current,
and temperature
protection
Each output has over-voltage, over-current, and over-temperature protection. Over-
voltage and over-current protection are programmable. When activated, the
protection circuits cause the voltage to go to zero, the output to be disabled, and the
protection status to be reported.
System Features
SCPI language The instrument is compatible with the Standard Commands for Programmable
Instruments (SCPI).
Choice of three
interfaces
GPIB (IEEE-488), LAN, and USB (mini B) remote programming interfaces are
built in.
Front panel I/O
setup
Menus let you set up GPIB and LAN parameters from the front panel. Refer to
Chapter 3 for details.
Built-in Web
server
A built-in Web server lets you control the instrument directly from an internet
browser on your computer. Refer to Chapter 3 for details.
Real-time status
information
The front panel indicates the status of each output. It also indicates when a
protection shut-down has occurred.
Module
identification
Each module has identifying data stored in non-volatile memory. Information
includes model number, serial number, and options. This information can be
displayed on the front panel.
Model Differences
Feature DC Power Modules (A+B) Autoranging Modules Precision Modules
N6731 -
N6736
N6741 -
N6746
N6751A N6752A N6761A N6762A
Output power rating 50 W
1
100 W
2
50 W 100 W 50 W 100 W
Autoranging output capability NO NO YES YES YES YES
Precision output and measurement capability NO NO NO NO YES YES
Low voltage output and measurement range NO NO NO NO YES YES
Low current output and measurement range NO NO NO NO YES YES
Simultaneous voltage and current measurement NO NO NO NO YES YES
Output list capability (Test Extensions) NO NO Option Option YES YES
Array readback capability (Test Extensions) NO NO Option Option YES YES
Programmable sample rate (Test Extensions) NO NO Option Option YES YES
1
Model N6735A has a maximum output of 40 W.
2
Models N6742A and N6745A have a maximum output of 80 W.
