6 Language Dictionary
98 Series N6700 User’s Guide
STATus:PRESet
This command sets all defined bits in the Status system’s PTR
registers and clears all bits in the NTR and Enable registers.
Operation Register Questionable Register Preset Settings
STAT:OPER:ENAB STAT:QUES:ENAB 0 all bits disabled
STAT:OPER:NTR STAT:QUES:NTR 0 all bits disabled
STAT:OPER:PTR 31 all defined bits enabled
STAT:QUES:PTR 3647 all defined bits enabled
STATus:OPERation[:EVENt]? (@<chanlist>)
This query returns the value of the Operation Event register. The
Event register is a read-only register, which stores (latches) all
events that are passed by the Operation NTR and/or PTR filter.
Reading the Operation Event register clears it. The bit configuration
of the Operation status registers is as follows:
Bit Position 15-5 4 3 2 1 0
Bit Value
−
16 8 4 2 1
Bit Name
−
WTG-tran WTG-meas OFF CC CV
WTG-tran = The transient system is waiting for a trigger.
WTG-meas = The measurement system is waiting for
a trigger
OFF = The output is programmed off
CC = The output is in constant current
CV = The output is in constant voltage
STATus:OPERation:CONDition? (@<chanlist>)
This query returns the value of the Operation Condition register.
That is a read-only register, which holds the live (unlatched)
operational status of the power system.
STATus:OPERation:ENABle <value>, (@<chanlist>)
STATus:OPERation:ENABle? (@<chanlist>)
This command and its query set and read the value of the
Operational Enable register. This register is a mask for enabling
specific bits from the Operation Event register to set the operation
summary bit (OPER) of the Status Byte register. This bit (bit 7) is the
logical OR of all the Operational Event register bits that are enabled
by the Status Operation Enable register.
