109
Configuring the Station
■ End Time
How to delete Daily Schedule
1. Select the day for which to delete a schedule from "Calendar."
2. Schedules for the selected day are displayed in the "Set schedule list."
• If a weekly schedule is configured for the selected day of the week, it will also be displayed.
3. Click [Delete] for the schedule to delete, and then click [Update].
• Refer to “How to delete the Weekly Schedule (→page 107)” for information on deleting weekly schedules.
5.2.2 Option Relay Control Authentication Key
Description Configure the time to stop relay output. If this is set earlier than “Start Time (→page 108)”, the
end time will be for the following day.
Settings 00:00 - 23:59
Default values -
Description If “Option Relay Control (→page 105)” is set to "Enable" and "Speed Dials / Favorites" - "TLS" is
set to "Enable" for the station to control, configure the key used to decrypt encrypted
communication.
If this matches the "Option Relay Control Key" of the station performing the operation, the output
terminal can be controlled.
Settings 1 - 20 digits
Default values —
Note
• The "Option Relay Control Authentication Key" is displayed as "●●●●●" in the Settings window.
• A single Option Relay Control Authentication Key can be configured for a station. It will be shared among multiple output
terminals.
