50
Settings and Adjustments
Configuring the device on a PC
4
■ Video Encoder 2
Set when transmitting video using ONVIF.
To view video from IX-DV or IX-DVF(-*) with a 3rd party product, refer to
“Viewing video from IX-DV or IX-DVF(-*) with
3rd party products (ONVIF) (→page 88)”.
*1 Indicates a required field. The settings should be entered. Retain the default values, unless a change is necessary.
Important
• Settings may be changed by request from the connected 3rd party product. For details, refer to the manual of the connected
3rd party product.
Note
• The frame rate or bit rate may be lower than the set value depending on the video being sent, the number of recipient stations,
and the network environment.
Entry Description Settings Default values
Second Video
Encoder
Enable / Disable the dual stream function.
Set to "Enable" when transmitting video
through ONVIF.
• Enable
• Disable
Enable
Video Codec Select the coding system for the video. • H.264 / AVC
• Motion-JPEG
H.264 / AVC
Resolution Select the resolution for the video. • 320×240 (QVGA)
• 640×480 (VGA)
• 800x480(WVGA)
• 1280x720(HD)
• 1280x960(SXVGA)
1280x720(HD)
Frame Rate [fps] Select the frame rate. 1, 2, 3, 5, 7.5, 10, 15, 20, 30 10 fps
Select Profile [H.264 /
AVC]
Configure the profile for H.264/AVC. • Baseline
• Main
• High
Main
I-picture interval
[H.264/AVC]
*1
Configure the interval for transmitting I-
pictures with H.264/AVC.
1 - 100 10
Bit rate [kbps] [H.264 /
AVC]
Configure the bit rate for H.264/AVC. 32, 64, 128, 256, 384, 512,
768, 1024, 2048, 4096, 8192
2048 kbps
Select Quality [Motion-
JPEG]
Configure the Motion-JPEG image quality. 1 (low) to 10 (high) 6
To Next Page
