Operational Summary
The seven front panel pushbuttons allow you to select display menu groups.
The two knobs allow you to change menus and set parameters within the menu
groups. These functions can be summarized as follows:
• Select a menu group: Press one of the seven pushbuttons.
• Scroll through menus in a group: Turn SELECT.
• Edit a menu parameter: Stop SELECT on the menu.
• Change a parameter value: Once the parameter is selected with SELECT, turn
ADJUST to set the value. Changes are applied immediately.
• To edit a multiple part parameter, such as the IP address, push the ADJUST
knob momentarily (the value blinks). To save the whole parameter after
editing, push ADJUST momentarily again.
• Coarse adjust a value (for use with parameters that have more than 10
selections):
• 10x speed - Hold down the menu group button (the button turns blue) and
turn ADJUST. The values will change in 10x increments.
• 100x speed (available for extremely wide-range parameters, like Audio
Delay) - After enabling 10x speed above, momentarily release and press that
group button a second time (the button turns light blue). Turning ADJUST
will now change the value in 100x increments.
• Undo a change (restore previous setting): Push SELECT momentarily.
• Reset to factory default: Hold down ADJUST for 4 seconds.
Button Operation Rules
The general rules of Menu Group button operation are:
• Press one of the Menu Group buttons to access the associated menu group.
The SELECT and ADJUST knobs control the display menus.
• The selected Menu Group button lights and the other buttons go low tally
• Each menu group returns to the last menu changed when you select the
button. After a reboot, each group displays the last menu selected.
• Hold down a button (turns blue) to make coarse adjustments using the
ADJUST knob. Release the button to make ne adjustments (see above).
STATUS
Displays the Status Menu Group, which shows current machine status and error
conditions:
• Video Input and status
• Caption status
• Reference and Genlock status
• Output status
• Power and Temperature status
• System Name display
• Alarms
REMOTE
Displays the Remote Menu Group, which lets you select how to control the FS3:
• Control by local front panel only, remote sources only, or local and remote
• Authentication
• GPI input and output behavior
