AJA FS3 - Proc Amp Controls (YUV)

FS3 Frame Synchronizer/Converter v1.1r1 52 www.aja.com
11.3 Matte Hue
This parameter determines the Matte Hue of the background fill.
0 degrees (default)
0–359 degrees (Variable)
Sets the matte hue to the default 0 degrees (red).
Sets the matte hue to a value between 0 and 359 degrees.
NOTE: On the front panel, as you turn the Matte Hue ADJUST knob the values wrap from
359 back to 0 degrees.
Proc Amp Controls (YUV)
These parameters determine the processing amp controls applied to YUV signals.
12.0 Proc Amp (YUV)
This parameter turns the Proc Amp On and Off for signals composed of YUV
components. When it is On, you can set additional parameters to control video
Gain, Black Level, Hue, and Saturation.
O (default)
On
Sets the YUV Proc Amp to O.
Sets the YUV Proc Amp to On.
Source Memory
Independent Proc Amp parameter values are kept for each input format.
12.1 Proc Amp Gain
This parameter adjusts the video gain from 0 to 1.5 times luma in 0.01 steps
Variable Adjusts Proc Amp Gain from zero to 1.5 in 0.01 steps.
Default (unity): 1.0
12.2 Proc Amp Black
This parameter adjusts the video black level from -20 IRE to +20 IRE in 0.5 steps.
Variable Adjusts Proc Amp Black level from -20 IRE to +20 IRE in 0.5 steps.
Default (unity): 0 IRE
12.3 Proc Amp Hue
This parameter adjusts the video color hue through 360 degrees (color wheel) in
1 degree steps.
Variable Adjusts Proc Amp Hue from -179 to +180 in steps of 1 degree.
Default (unity): 0 degrees
12.4 Proc Amp Sat
This parameter adjusts the video color saturation from black and white to 1.5
times chroma in steps of 0.01.
Variable Adjusts Proc Amp Saturation from 0 (black & white) to 1.5 (Chroma) in
steps of 0.01.
Default: 1.0
