Presets Screen
The Presets screen allows you to save FS3 Preset Configurations into 40 separate
memory registers and recall the presets whenever needed. This screen also
includes Export and Import functions that allow exporting one or all FS3
presets to your computer as files and importing exported preset files from your
computer. A displayed message indicates successful or failed saves, recalls,
exports, and imports.
Presets Screen Controls
Factory Preset
Factory Preset recalls all editable video and audio parameters to their factory
default settings. Individual presets, user preferences, and Network settings, such
as the IP Address, are not affected.
Recall
The Recall buttons recall saved FS3 preset configurations.
Caution! When you recall a Preset Conguration, the recalled preset immediately
replaces the system’s existing conguration. All previous settings are lost unless
you have previously stored them in another preset conguration or an exported
le.
Store
The Store buttons let you save the current FS3 configuration into the preset
register with the associated name and number. A preset is a set of all System,
Video, Audio, and Output parameters as they were set at the time the preset
was stored. Only editable parameters are saved in the presets. Non-editable
parameters are not saved.
To change a preset name, click in the name’s text field, type a new name, and
press Enter to save the name. After entering text, you can click the mouse outside
of the edit box to exit without changing the name.
