AJA FS3 - Control Knobs

FS3 Frame Synchronizer/Converter v1.1r1 15 www.aja.com
• 5.1 and 7.1 Mix Down adjustments
• Audio source selections
• Global output selection
• Output mapping controls
Control Knobs
These are the general rules of SELECT and ADJUST knob operation:
SELECT
Turning the SELECT knob performs these actions:
• Turn SELECT in either direction to scroll through the menus.
• Stop on a menu to enter that menu for editing.
• Turn SELECT within a menu to scroll through multiple parameters.
• Pause on a parameter to select it for editing. For multiple elds in a parameter,
use SELECT to move through the elds (after pressing ADJUST to enter eld
editing mode).
• Push SELECT momentarily to undo and restore the previous setting.
ADJUST
Turning the ADJUST knob performs these actions:
• Turn ADJUST to change the values of a selected parameter.
• In most cases, leaving a value in place for a moment sets that value.
• To perform special actions, such as recalling a register, push the knob to
conrm the displayed value. Display line 4 indicates such special actions.
• Some parameters having multiple elds, such as IP Address require you to
push the DJUST knob to select a eld, and push again to save changes.
• Hold down the knob to reset a value to the factory default; for multiple eld
values, all elds are reset to the default.
• When the STATUS button is selected, pressing ADJUST returns the user to the
last mode and menu selected before SYSTEM -> STATUS was selected.
Table 1. SELECT and ADJUST Knob Operation Summary
Function Knob Action
Scroll through menus.
Scroll through parameters in a multiparameter menu.
Scroll through numerals or letters in a parameter.
Turn SELECT backwards or forward.
Enter edit mode for a menu.
Enter edit mode for a parameter.
Enter edit mode for values, numerals, or letters.
Advance to the next value, numeral, or character to edit.
Turn and stop SELECT on the item to edit. (For some
multiple parameter menus, push ADJUST so that the
selected parameter blinks.)
Increment/decrement a value. Turn ADJUST.
Coarse adjust a value. 10x speed - Hold down button (turns blue) and turn
ADJUST.
- or -
100x speed - Hold down button (turns blue),
momentarily release and press button again (turns
light blue) and turn ADJUST.
Reset a value to the factory default value.
Set a number to the default value (typically zero).
Hold down ADJUST.
