Switching from Global to Channel Pair will apply the individual delay values that
were set for each individual channel pair. Switching from Channel Pair to Global
will apply the same currently set Global delay value to all the channel pairs.
3.1 SDI 1 Delay Global
When Global is selected above, the individual SDI 1 audio channel pair menus are
hidden.
SDI 1 Delay Global The ADJUST knob sets the Global delay value. Adjustment range is
-768 to +12288 in units of samples where 48 samples = 1 millisecond.
The Front Panel displays the delay in milliseconds and as fractions of
milliseconds in units of samples.
3.1-3.8 SDI 1 Channel Pair Delay
When Channel Pair is selected above, eight individual SDI 1 audio channel pair
menus become available, permitting adjusting the delay of each input channel
pair.
• Delay adjustment range is -768 to +12288 in units of samples where 48
samples = 1 millisecond. The Front Panel displays the delay in milliseconds
and as fractions of milliseconds in units of samples.
4.0/5.0/6.0 SDI 2 Level, Phase, Delay
See descriptions for SDI 1:
• "1.0 SDI1 Level" on page 63
• "2.0 SDI1 Phase" on page 64
• "3.0 SDI1 Delay" on page 64
7.0/8.0/9.0 Fiber1 Level, Phase, Delay
See descriptions for SDI 1:
• "1.0 SDI1 Level" on page 63
• "2.0 SDI1 Phase" on page 64
• "3.0 SDI1 Delay" on page 64
10.0/11.0/12.0 Fiber2 Level, Phase, Delay
See descriptions for SDI 1:
• "1.0 SDI1 Level" on page 63
• "2.0 SDI1 Phase" on page 64
• "3.0 SDI1 Delay" on page 64
13.0 Mix Down Mode
This parameter activates the Mix Down mixer, and selects either 5.1 or 7.1 mix
down mode.
O (default)
5.1 Channel
7.1 Channel
Mix down feature is turned o.
Selects 5.1 mix down mode.
Selects 7.1 mix down mode.
When set to 5.1 or 7.1 Channel Mode, additional menus follow that are used to
select the source of the incoming multi-channel audio, adjust the levels of each
of the incoming channels to the Left and Right outputs, and adjust the gain of the
Left and Right output channels.
