Alber BDS-40 - Figure 10. Lock Washer; Figure 11. Screws; Figure 9. Tab Washers

Product Overview
4200–045
11
6/5/2017
Standard Materials
Description
Purpose
tab washers
pn 2120–060B
Figure 9. Tab Washers
Connector interface between
harness and cell.
Refer to drawing BDS–1179–
A581.
NOTE:
Tab washer size is battery
dependent, other sizes
such as 3/8” and 5/16” are
readily available.
lock washers
pn 2825–060
Figure 10. Lock Washer
various screws
pn 2825–115
Figure 11. Screws
