Product Overview
4200–045
13
6/5/2017
5.5.1 Optional
Optional Materials
Description
Purpose
FCCP Kit
pn 5610–051
FCCP Cable pn
1101–749
Figure 15. Multitel Float Charging
Current Probe Kit
Float current measurement
transducer for a single string.
Please refer to drawings BDS–
1189–B985
NOTE:
Part number 5610–050
supports two strings and
includes one more clamp
on the probe.
24V .5A DC Wall
Mount Power
Supply
pn 4000–026
Figure 16. AC Wall
Plug Transformer
24V .5A DC Wall Mount Power
Supply for the FCCP
Ambient
temperature
probe/assembled
with cable
pn 1101–745
Separate ambient
probe shown in
figure pn 2900–
029
Cable pn 6002–
094
Figure 17. Ambient Temperature
Probe & Assembled pn 1101–745
Temperature probe that hangs
free for ambient temperature
measurement. Refer to drawing
BDS–1189–B985.
