Alber BDS-40 - System Configurations

BEFORE SYSTEM INSTALLATION
4200–045
17
6/5/2017
The following drawings are required for BDS–40 installation. The drawings in this
manual may not be the most recent revision and are included for reference only.
Drawing
Number
General Assembly, Base Unit
BDS–377–D1695
General Assembly, Plus Unit
BDS–378–D1696
Application Details
BDS–5274–B1054
Installation Details, Tab Washer Quick Connect Sense/Load Leads
BDS–1179–A581
Connection Details, Optional Sensors
BDS–1189–B985
Connection Details, Power, Data, Alarm Contact Connections
BDS–1193–B986
Mounting Detail, Cabinet Top Mounting Dimensions
BDS–1178–D1687
Wiring Schematic, BDS–40 to (40) 12V Modules, (10 Shelf)
Battery
BDS–2287–B960
WARNING:
The BDS system is designed to connect to UPS systems that are 600VDC or less and a
maximum of 300V with respect to earth ground. The user must verify the voltage with
respect to earth ground before connecting the system. Do this by measuring the voltage
from each battery post referenced to earth ground. The voltage cannot exceed 300V.
6.2 System Configurations
This section is an overview of the BDS–40 monitor configurations. The BDS–40 model numbers
are structured as follows. Thus, a typical model number might be 1002–750A CRAA21.
1002–nnn XXxxxxxx
1003–nnn XXxxxxxx required for 16V jars
The BDS–40 model. This is 1002– followed by:
750 to indicate a Base Unit or
751 to indicate a Plus Unit.
This group of letters/numbers indicates cabinet options/configurations:
Position XXxxxxxx
Cabinet Options
Cabinet Configurations
A_xxxxxx
1X40X12, 10S of 4J
B_xxxxxx
1X40X12, 4S of 10J
C_xxxxxx
1X36X12, 4S of 9J
D_xxxxxx
1X36X12, 3S of 12J
E_xxxxxx
1X30X12, 5S of 6J
