Product Overview
4200–045
14
6/5/2017
Optional Materials
Description
Purpose
600 amp CT
pn 1101–748
Figure 18. 600 Amp Current
Transducer CT Assembly
BDS–40 CT with Cable Assembly
Use Drawing BDS–1189–B985
PHOTOS VARY DEPENDING
UPON MODEL(S) CHOSEN UP
TO 3000 AMPS
NOTE:
5610–019 Is the part
number for the 600 amp
CT and it can be ordered
with a cable assembly pn
1101–748.
5.6 Tools
The following tools or equivalents may be necessary for BDS–40 System installation:
NOTE:
Most harness work and crimping has been done at the factory for ease of installation.
TOOLS
Description
Purpose
Panduit CT–260
crimper Albércorp.
pn 5400–002
Figure 19. Panduit CT–260
Crimper
For parallel splices
Panduit CT–1525
crimper Albércorp.
pn 5400–007
Figure 20. Panduit CT–1525
Crimper
For crimping ring terminals –
NOTE:
Most of the work has
been done at the
factory, but occasionally
the user may need this
tool.
