15
LIVE VIEW / SNAPSHOT / VIDEO RECORD
Main page
Function Description
System Name & View Mode Display the name of the camera assigned by user and current
view mode (Live-View or Playback).
Connection Status Indicating the connection status (Connected or Disconnected)
between the app and the camera.
Video Resolution Indicating the video resolution, either VGA (640*480) or HD
(1280*720)
Camera Mode Battery Mode - power by battery, camera on only
after detects motion to conserve battery power.
USB Mode - power by adaptor, camera always on
for anytime remote view.
Snapshot Tap icon to take snapshot(s). Captured images are stored in the
mobile device.
Video Record Tap icon to manually start recording. Each recording session
will last for 5s, 10s, 15s or 30s and cannot be stopped during
the recording period. Captured videos are stored in the memory
card of the camera.
Return Tap icon to return to the main page (device list).
System Name & View Mode
Camera Mode
Return
Video Record
Connection Status
Video Resolution
Snapshot
Battery
Battery
USB
