— 9 —— 8 —
INSTALLATION
Installing the Camera
y
Insert the two 18650 batteries and
connect the wires as shown. The camera
will power up and the status LED will
blink red/blue to indicate it is ready to be
paired. Make sure the battery wires are
firmly connected to the camera, or press
and hold the Reset button until the status
LED blinks red/blue.
You can also use the supplied AC
Adapter by connecting the small end of
the AC adapter to the camera’s USB
Jack. Plug the other end of the adapter
to a 120 volt AC (standard indoor) power
outlet.
The LED will blink blue and red.
U
You can use the bottom mount or the
rear mount to secure the camera to
the Camera Bracket as follows:
u Align one of the Mounting sockets on the
camera with T-Bolt and screw camera
onto the T-Bolt until it is in the desired
position.
v Tighten the Brace against the camera to
secure it in place.
V
The camera is now ready to be set up on
an Android or Apple device as shown in
pages 11 or 16.
v
u
UP
UP
