IPSEC
Page 124 7750 SR RADIUS Attributes Reference Guide
Table 39: IPSEC (limits)
Attribute ID Attribute Name Type Limits SR OS Format
1 User-Name string 253 bytes # Format depends on IDi format.
For example: User-Name =
“user1@domain1.com”
2 User-Password string 64 bytes -
8 Framed-IP-Address ipaddr 4 bytes For example: Framed-IP-Address =
192.168.10.100
9 Framed-IP-Netmask ipaddr 4 bytes For example: Framed-IP-Netmask =
255.255.255.0
30 Called-Station-Id string 253 bytes # local gateway address of IKEv2
remote-access tunnel.
For example: Called-Station-Id =
“172.16.100.1”
31 Calling-Station-Id string 253 bytes # peer-address:port
For example: Calling-Station-Id =
“192.168.5.100:500”
44 Acct-Session-Id string 147 bytes # local_gw_ip-remote_ip:remote_port-
time_stamp.
For example: Acct-Session-Id =
172.16.100.1-192.168.5.100:500-
1365016423
46 Acct-Session-Time integer 4 bytes
4294967295
seconds
For example: Acct-Session-Time = 870
79 EAP-Message string 253 bytes Binary string
80 Message-Authenticator string 16 bytes Binary string
87 Nas-Port-Id string 44 bytes # SAP-ID
For example:
Nas-Port-Id = “tunnel-1.public:100”
97 Framed-IPv6-Prefix ipv6prefix max. 16 Bytes
for prefix + 1
byte for length
For example:
Framed-IPv6-Prefix =
2001:DB8:CAFE:1::100/128
26-311-16 MS-MPPE-Send-Key string 254 bytes Binary string
26-311-17 MS-MPPE-Recv-Key string 254 bytes Binary string
26-6527-9 Alc-Primary-Dns ipaddr Up to 4
attributes (4B
per attribute)
For example:
Alc-Primary-Dns = 192.168.1.1
