Business Service Access
Page 78 7750 SR RADIUS Attributes Reference Guide
Table 12: Business Access (limits)
Attribute ID Attribute
Name
Type Limits SR OS Format
22 Framed-Route string max. 16
Framed-Route
attributes
"<ip-prefix>[/<prefix-length>] <space> <gateway-
address> [<space> <metric>] [<space> tag <space>
<tag-value>] [<space> pref <space> <preference-
value>]”
where:
<space> is a white space or blank character
<ip-prefix>[/prefix-length] is the managed route to be
associated with the routed subscriber host. The prefix-
length is optional and if not specified, a class-full class
A,B or C subnet is assumed.
<gateway-address> must be the routed subscriber host
IP address. “0.0.0.0” is automatically interpreted as the
host IPv4 address.
[<metric>] (Optional) Installed in the routing table as
the metric of the managed route. If not specified, metric
zero is used. Value = [0.. 65535]
[tag <tag-value>] (Optional) The managed route will be
tagged for use in routing policies. If not specified or
tag-value=0, then the route is not tagged. Value =
[0..4294967295]
[pref <preference-value>] (Optional) Installed in the
routing table as protocol preference for this managed
route. If not specified, preference zero is used. Value =
[0..255]
For example:
Framed-Route = "192.168.1.0/24 0.0.0.0" where
0.0.0.0 is replaced by host address. Default metrics are
used (metric=0, preference=0 and no tag)
Framed-Route = "192.168.1.0 0.0.0.0" where
192.168.1.0 is a class-C network /24 and 0.0.0.0 is
replaced host address. Default metrics are used.
Framed-Route = "192.168.1.0/24 192.168.1.1" where
192.168.1.1 is the host address. Default metrics are
used.
Framed-Route = "192.168.1.0 0.0.0.0 10 tag 3 pref
100" installs a managed route with metric=10, protocol
preference = 100 and tagged with tag=3
Framed-Route = "192.168.1.0 0.0.0.0 tag 5" installs a
managed route with metric=0 (default), protocol
preference = 0 (default) and tagged with tag=5"
