WLAN Gateway
Page 106 7750 SR RADIUS Attributes Reference Guide
Table 29: WLAN Gateway (limits)
Attri-
bute ID
Attribute
Name
Type Limits SR OS Format
4 NAS-IP-
Address
ipaddr 4 Bytes For example:
NAS-IPAddress = 10.1.1.2
30 Called-
Station-Id
string 64 chars. For example:
Called-Station-Id = “0a-0b-0c-00-00-01 : AirportWifi”
31 Calling-
Station-Id
string 64 chars. For example:
Calling-station-id = 00:00:00:00:00:01
87 NAS-Port-Id string 253 chars. L2TP | GRE: “<tunnel-type> rtr-<virtual router id>#lip-
<local ip address>#rip-<remote ip address>”
VLAN: “VLAN svc-<svc-id>[:<vlan>[.<vlan>]]”
For example:
NAS-Port-Id = “GRE rtr-11#lip-50.1.1.1#rip-201.1.1.2”
26-3561-1 Agent-Circuit-
Id
string 247 chars. String containing information about the AP and the SSID
that the UE is associated with. Recommended format is
<AP-MAC>;<SSID-Name>;<SSID-Type>. SSID-Type can
be open (‘o’), or secure (‘s’)
For example:
Agent-Circuit-Id = “00:00:00:00:00:01;xfinity-wifi;o”
26-6527-
145
Alc-MGW-
Interface-Type
integer values [1..3] Gn(GTPv1)=1; S2a(GTPv2)=2; S2b(GTPv2)=3
default = s2a
For example: Alc-MGW-Interface-Type = 1
26-6527-
146
Alc-Wlan-
APN-Name
string 100 chars. if
both <NI> and
<OI> parts are
present.
63 chars. if
only the <NI>
part is present.
The APN Name attribute must be formatted as
<NI>[.mnc<MNC>.mcc<MCC>.gprs]. The Operator-ID
(OI) part is optional and is automatically derived from the
IMSI if it is not present.
The APN FQDN generated for DNS resolution is composed
of the Network-ID (<NI>) portion and the Operator-ID (OI)
portion (<MCC> and <MNC>) as per 3GPP TS 29.303 and
is reformatted as
<NI>.apn.epc.mnc<MNC>.mcc<MCC>.3gppnetwork.org
For example: Alc-Wlan-APN-Name =
wlangw.mnc004.mcc204.gprs
26-6527-
147
Alc-MsIsdn string 9..15 digits For example: Alc-MsIsdn = 13109976224
26-6527-
148
Alc-RSSI integer 32 bit value For example: Alc-RSSI = 30
26-6527-
149
Alc-Num-
Attached-Ues
integer 32 bit value For example: Alc-Num-Attached-Ues = 3
