RADIUS Attributes Reference
7750 SR RADIUS Attributes Reference Guide Page 117
Lawful Intercept
Table 35: Lawful Intercept (description)
Attribute ID Attribute Name Description
26-6527-122 Alc-LI-Action Defines the traffic mirroring action start-mirroring 'enable' or stop-mirroring
'disable'. The Alc-LI-Action 'no-action' specifies that the router does not
perform any traffic mirroring-related action. This setting can provide
additional security by confusing unauthorized users who attempt to access
traffic mirroring communication between the router and the RADIUS server.
The CoA-only 'clear-dest-service' Alc-LI-Action creates the ability to delete
all li-source entries from the mirror service defined via the Alc-LI-Destination
service-id. A 'clear-dest-service' action requires an additional [26-6527-137]
Alc-Authentication-Policy-Name if the CoA server is configured in the
authentication policy. Values outside the Limits are treated as a setup failure.
2 6-6 52 7-1 23 A lc -L I-D es tin at ion S pec if ies th e <service-id> that holds the mirror details (configure mirror
mirror-dest <service-id>). Values above the Limits or unreferenced are
treated as a setup failure.
26-6527-124 Alc-LI-FC Defines which Forwarding Class(es) (FC's) have to be mirrored (example:
Alc-LI-FC=ef). Attribute needs to be repeated for each FC's that needs to be
mirrored. Values above the Limits are treated as a setup failure and all FC's
will be mirrored if attribute is omitted. Additional Attributes above the Limits
are silently ignored.
26-6527-125 Alc-LI-Direction Defines if ingress, egress or both traffic directions needs to be mirrored. Both
directions are mirrored if Attribute is omitted. Values above the Limits are
treated as a setup failure.
26-6527-137 Alc-Authentication-
Policy-Name
Used when clearing all radius li triggered sources from a mirror destination
via CoA ([26-6527-122 Alc-LI-Action = 'clear-dest-service'). The policy
defined in this attribute is used to authenticate the CoA and refers to
configure subscriber-mgmt authentication-policy <name>. The attribute is
mandatory if the RADIUS CoA server is configured in the authentication
policy (config>subscr-mgmt>auth-plcy>radius-auth-server). The attribute
is ignored if the RADIUS CoA server is configured in the radius-server
context of the routing instance (config>router>radius-server or
config>service>vprn>radius-server). Values above the Limits or
unreferenced policies are treated as a setup failure.
26-6527-138 Alc-LI-Intercept-Id Specifies the intercept-id to be placed in the LI-Shim header and only
applicable if the mirror-dest (as specified by the Alc-LI-Destination) is
configured with routable encap that contains the LI-Shim. A zero can be
returned in CoA or RADIUS Accept or the value of 0 is used if this VSA is
not present at all. The length of the attribute changes if the CLI parameter
direction-bit (dir-bit) under the mirror-dest layer-3-encap is enabled or not
(see limits).
