RADIUS Attributes Reference
7750 SR RADIUS Attributes Reference Guide Page 173
97 Framed-IPv6-Prefix ipv6prefix max. 16 Bytes
for prefix + 1
Byte for
length
PPPoE SLAAC wan-host <ipv6-prefix/prefix-
length> with prefix-length 64
For example: Framed-IPv6-Prefix
2021:1:FFF3:1::/64
99 Framed-IPv6-Route string max. 16
Framed-IPv6-
Route
attributes
<ip-prefix>/<prefix-length> <space> ::
<space> <metric> [<space> tag <space> <tag-
value>] <space> pref <space> <preference-
value>”
The gateway address is always reported as
"::", representing the wan host ip.
For example:
Framed-IPv6-Route = "5000:0:1::/56 :: 0 pref
0" corresponds with a managed route with
default metrics (metric=0, no tag,
preference=0)
Framed-IPv6-Route = "5000:0:1::/56 :: 10 tag
3 pref 100" corresponds with a managed route
with metric=10, tag=3 and preference=100
123 Delegated-IPv6-Prefix ipv6prefix max. 16 Bytes
for prefix + 1
Byte for
length
<ipv6-prefix/prefix-length> with prefix-length
[48..64]
For example: Delegated-IPv6-Prefix
2001:DB8:173A:100::/56
26-3561-1 Agent-Circuit-Id string 247 chars format see also RFC4679 # ATM/DSL
<Access-Node-Identifier><atm slot/
port:vpi.vci> # Ethernet/DSL <Access-Node-
Identifier><eth slot/port[:vlan-id]>
For example: ethernet dslam1 slot 2 port 1
vlan 100 Agent-Circuit-Id = dslam1 eth 2/
1:100
26-3561-2 Agent-Remote-Id string 247 chars format see also RFC4679
For example: Agent-Remote-Id =
MyRemoteId
26-3561-129 Actual-Data-Rate-
Upstream
integer 4294967295
bps
For example: # 1Mbps Actual-Data-Rate-
Upstream = 1000000
26-3561-130 Actual-Data-Rate-
Downstream
integer 4294967295
bps
For example: # 5Mbps Actual-Data-Rate-
Downstream = 5000000
26-3561-131 Minimum-Data-Rate-
Upstream
integer 4294967295
bps
For example: Minimum-Data-Rate-Upstream
= 1000
26-3561-132 Minimum-Data-Rate-
Downstream
integer 4294967295
bps
For example: Minimum-Data-Rate-
Downstream = 1000
Table 53: Enhanced Subscriber Management Accounting (limits) (Continued)
Attribute ID Attribute Name Type Limits SR OS Format
