Alcatel-Lucent 7750 - Table 60: LSN Accounting (Limits)

RADIUS Attributes Reference
7750 SR RADIUS Attributes Reference Guide Page 199
26-6527-121 Alc-Nat-Port-Range Holds for the NAT user his public outside ipv4 address, his assigned outside
public port range and the outside routing instance. For LSN accounting, the
attribute is sent when port-range-block is included under configure aaa isa-
radius-policy.
The attribute is also sent for ESM subscriber accounting if NAT is enabled
and if configured in configure subscriber-mgmt radius-accounting-policy
<name> include-radius-attribute nat-port-range.
26-6527-140 Alc-Nat-Outside-Serv-
Id
Refers to the public outside service-id and send when outside-service-id is
included under configure aaa isa-radius-policy and the service-id is different
than the base instance.
26-6527-141 Alc-Nat-Outside-Ip-
Addr
Holds for the NAT user his public outside ipv4 address and send when
outside-ip is included under configure aaa isa-radius-policy <name>. The
content of this attribute is identical to the outside ipv4 address in [26-6527-
121] Alc-Nat-Port-Range.
Table 59: LSN Accounting (description) (Continued)
Attribute ID Attribute Name Description
Table 60: LSN Accounting (limits)
Attribute ID Attribute Name Type Limits SR OS Format
1 User-Name string [32|64] chars Subscriber unaware: LSN44@<ipaddr>, DS-
lite@<ipv6addr> and
NAT64@<ipv6addr>Subscriber aware: format and
length depends on the subscriber-identification
attribute configuration- attribute-type alc-sub-
string max 32 chars- attribute-type user-name ,
class and station-id max 64 chars- attribute-type
imsi and imei max 32 chars
For example:# subscriber unaware: NAT64 host
ipv6 address 2001::0001User-Name =
NAT64@2001:0000:0000:0000:0000:0000:0000:
0001# subscriber aware: NAS subscriber-id =
private-user1 and subscriber-identification alc-sub-
stringUser-Name = private-user1
4 NAS-IP-Address ipaddr 4 Bytes For example:# ip-address 10.1.1.1NAS-IP-
Address 0a010101
