Enhanced Subscriber Management (ESM) Accounting
Page 172 7750 SR RADIUS Attributes Reference Guide
55 Event-Timestamp date 4 Bytes For example: # Jul 6 2012 17:28:23 CEST is
reported as 4FF70417 Event-Timestamp =
4FF70417
61 NAS-Port-Type integer 4 Bytes
Values
[0..255]
Values as defined in rfc-2865 and rfc-4603
For LNS, the value is set to virtual (5)
For example: NAS-Port-Type =
PPPoEoQinQ (34)
87 NAS-Port-Id string 253 Bytes <prefix> : optional string 8 chars max
<suffix> : optional string containing remote-
id ( max 64 chars) or circuit-id ( max 64 chars)
# IPoE/PPPoE:
“<prefix><space><slot>/<mda>/<port>/
<vlan>.<vlan><space><suffix> # ATM :
<prefix><space><slot>/<mda>/<port>/
<vpi>.<vci><space><suffix>”
For example:
NAS-Port-Id = “1/1/4:501.1001”
# LNS:
“LNS rt-<routing instance>#lip-<tunnel-
server- endpoint>#rip-<tunnel-client-
endpoint>#ltid-<local-tunnel-id>#rtid-
<remote-tunnel- id>#lsid-<local-session-
id>#rsid-<remote- session-id>#<call sequence
number>”
For example:
NAS-Port-Id = “LNS rtr-2#lip-3.3.3.3#rip-
1.1.1.1#ltid-11381#rtid-1285#lsid-
30067#rsid-19151#347”
# WLAN-GW:
GRE or L2TPv3: “<tunnel-type> rtr-<virtual
router id>#lip-<local ip address>#rip-<remote
ip address>”
VLAN: “VLAN svc-<svc-
id>[:<vlan>[.<vlan>]]”
For example:
NAS-Port-Id = “GRE rtr-11#lip-50.1.1.1#rip-
201.1.1.2”
95 NAS-IPv6-Address ipv6addr 16 Bytes # ipv6-address
For example: NAS-IPv6-Address =
2001:db8::1
96 Framed-Interface-Id ifid 8 Bytes For example: Framed-Interface-Id
02:00:00:ff:fe:00:00:01
Table 53: Enhanced Subscriber Management Accounting (limits) (Continued)
Attribute ID Attribute Name Type Limits SR OS Format
