When using VPN Setting option, you can set several parameters as follow:
VPN Setting
Enable VPN You can enable/disable VPN for phone and PC.
VPN Type: Choose the appropriate type of VPN.
VPN Server Addr
VPN server IP address.
VPN User Name VPN user name
VPN Password
The password is used for authentication
VLAN Setting
When using VLAN Setting option, you can set several parameters as follow:
VLAN Setting
Enable VLAN You can enable/disable VLAN for phone and PC
VID
[LAN/PC Port]
The VLAN ID you want the phone or PC to join
