Hardware components of the Alcatel-Lucent 8001 DeskPhone are described as follows:
ITEM DESCRIPTION
1
LCD Screen
Displays information about calls, messages, soft keys, time, date and
other relevant data:
• Call information — caller ID, call duration
• Icons (e.g. )
• Missed calls or second incoming caller's information
• Time and date
2
Light Status
Red-Flashing: There is an incoming call or an on holdcall.
Red-Steady: Hook-off or in conversation
3
Line Keys
Green-Steady: There is a conversation on-going on the line
Red-Flashing: There is an incoming call
Green-Flashing: The line is on hold
Dark: Accounts are idle
4
Soft Keys
These 4 programmable keys allow to open services or launch calls
(depending on what has been configured)
5
OK Key
Confirm the action
6
Navigation Keys
Scroll through the displayed information, and in the idle state:
UP: Open the "All CONTACT LOG"
DOWN: Open the "MISSED CALLS"
RIGHT: Open the "RECEIVED CALLS"
LEFT: Open the "DIALED CALLS"
7
C Key
Cancels actions or rejects an incoming call, and the other feature:
In the idle state: Open the "Phone Status".
Diagnosis: Press and hold 3 seconds to open "HardwareDiagnosis".
MUTE: "MUTE" feature is activated if you press this button during an
ongoing conversation.
8
Functions Keys
Conference\Redial\Transfer\Hold
9
Speaker Key
Toggles the hands-free speaker phone mode.
10
Keypad
Provides the digits, letters and special characters in context-sensitive
applications.
11
Headset Key
Toggles and indicates the headset mode.
12
Message Key
Indicates and accesses voice messages.
13
Volume Keys
Adjusts the volume of the handset, headset, speaker and ringer
