page 2-12 OmniSwitch 6250 Series Hardware Users Guide September 2009
Preliminary
9/28/09
OmniSwitch 6250-24
The front panel of the OS6250-24 chassis contains the following major components:
• System status LEDs
• (24) Unshared 10/100Base-T ports
• (2) Combo 10/100/1000Base-T or 100/1000BaseX
• (2) HDMI Stacking Ports
• Internal AC Power Supply
• External BPS
• Console port (RJ-45)
• USB port (USB 2.0)
NoteUSB port (USB 2.0). USB port is not supported in this release.
