OmniSwitch 6450 Hardware Users Guide September 2015 page 6-3
Power over Ethernet Specifications
The table below lists general specifications for Alcatel-Lucent’s Power over Ethernet support. For more
detailed power supply and Power Source Equipment (PSE) specifications, refer to Chapter 3,
“OmniSwitch 6450 Chassis and Hardware Components.”
* For OS6450-P10S switches, PoE support of up to ~75W per port is provided on ports 1 through 4.
These ports are labeled “HPoE” on the chassis front panel. HPoE at ~75W per port must be enabled via
the lanpower power command. PoE support of up to 30W per port is provided on PoE ports 5 through 8.
The maximum PoE power budget available for all ports is 280W.
IEEE Standards supported*
IEEE 802.3at
HPoE and IEEE 802.3at on OS6450-P10S only,
on ports 1 through 4; see important note below.
Default PoE administrative status Enabled
Default PoE operational status Disabled (PoE must be activated on a switch-
by-switch basis via the lanpower start
command.)
Models supporting PoE OS6450-P10, OS6450-P10S, OS6450-P24,
OS6450-P48
Cable distances supported 100 meters (approx.)
PoE-capable ports per switch 8 (OS6450-P10 and OS6450-P10S)
24 (OS6450-P24)
48 (OS6450-P48)
Default amount of inline power available* 31000 milliwatts
Range of inline power allowed* 3000 - 31000 milliwatts
3000 - 75000 milliwatts (OS6450-P10S only,
on ports 1 through 4; see important note below.)
PoE Power Available* OmniSwitch 6450-P10: ~ 90W
OmniSwitch 6450-P10S: ~ 280W
OmniSwitch 6450-P24: ~ 410W
OmniSwitch 6450-P48: ~ 780W
