You do not use a DHCP server Static mode • Refer to Table 2
• Obtain from your network
administrator:
• An IP address for the IP
Touch set
• The subnetwork mask
• The router address
• The TFTP server address,
which is the IP address of
the PowerCPU EE board
embedding the VoIP
board
4.7.1.2.3.3 Initializing the IP Touch set
To initialize the IP Touch set, refer to the table below.
Note:
In each of the three cases below, you can view the IP Touch set's software version after Step 2 by selecting
Version in the Main menu.
table 4.6: Initialization procedure
For an initiali-
zation that is
Procedure
Dynamic Alcatel 1. If necessary, enable the OXO Connect DHCP server (in OMC, Hardware and
Limits > LAN/IP Configuration > DNS/DHCP)
2. Connect the power supply.
3. After initialization phase 2 is completed and before phase 5 starts, press i, then
the # key.
The Main menu appears.
4. If the set was previously in static mode, select IP Parameters from the Main
menu.
The IP Parameters menu appears.
5. Select Dynamic and press the OK key.
6. Save by pressing the # key.
7. Exit the Main menu by pressing the * key.
Dynamic mode 1. Connect the power supply.
2. After initialization phase 2 is completed and before phase 5 starts, press i, then
the # key.
The Main menu appears.
3. If the set was previously in static mode, choose IP Parameters from the Main
menu.
The IP Parameters menu appears.
4. Choose Dynamic and press the OK key.
5. Save by pressing the # key.
6. Exit the Main menu by pressing the * key.
Chapter
4
Installation and Cabling
3EH21123USAA - Ed. 01 - April 2017 - Installation Manual 103/207
