Alcatel-Lucent OXO Connect Large - OXO Connect S

PowerCPU EE Front Stiffener
Zoom on SLI1/2 & AUX and ISDN T0 RJ45 Connectors / PowerCPU EE
ZA1Ground +12V
CenRg
A
CenRg
B
ZB1 ZA2 ZB2
1 2 3 4 5 6 7 8
SLI1/2 & AUX RJ45 pin-out
12345678
SLI1/2 &
AUX
1
2 34
5
67
8
RX+TX+ TX-RX-
1 2 3 4 5 6 7 8
ISDN T0 1 & 2 RJ45 pin-out
ISDN T0
2x T0 connections of Mini-MIX board
2x Z connections of Mini-MIX board
MODULE
Figure 2.1: Mini-MIX connections on PowerCPU EE Board
Equipment numbering:
• Slot 80 EN 01 for the first T0 access (80-001-01)
• Slot 80 EN 02 for the second T0 access (80-002-01)
• Slot 80 EN 09 for the first Z access (80-009-01)
• Slot 80 EN 10 for the second Z access (80-010-01)
2.2.2 OXO Connect S
Chapter
2
Hardware: Platform and Interfaces
3EH21123USAA - Ed. 01 - April 2017 - Installation Manual 20/207
