For performance and safety reasons, the whole system must always be coupled to the
ground. The ground must be connected before any other connections.
The ground protection connection terminal must always be connected to the ground.
Protective grounding terminal shall be permanently connected to the ground.
4.3.6 Power Up
Having made all the connections, it is now time to power up the system.
• Insert the mains cable in the socket on the rear of the unit.
• Press the ON/OFF button. The system will reinitialize (duration: 3 to 4 minutes).
To stop the system:
• Press the ON/OFF button, the RED LED will flash.
• Wait until the LED stops flashing and is lit steadily (between 15 seconds and 3 minutes depending
on the configuration): the system is switched off.
4.3.6.1 Power Up of Dedicated Terminals
On powering up, dedicated sets execute a self-test:
• Display Test
• Test of the LEDs or icons on the terminal and add-on module, if any
• Audio test
If this sequence is correct, the display on the dedicated terminals shows the system date: Monday 01
January 00h00.
After powering up, you can activate the system from a dedicated terminal or by OMC (refer to the
specific notice).
4.4 SIP Terminals
4.4.1 8001/8001G Deskphone
4.4.1.1 8001/8001G Deskphone Commissioning
4.4.1.1.1 Overview
The 8001/8001G Deskphone sets are plug&phone, which means they are automatically created in the
OXO Connect, when connected to the network. A default certificate in the system allows plug&phone.
4.4.1.1.2 Prerequisites
The 8001/8001G Deskphone software must be in version 3.6.0.5. If a previous software version is
installed on the set, the set starts as an "Open SIP Phone" and is not recognized as 8001/8001G
Deskphone SIP Phone".
The software is downloaded according to the initial 8001/8001G Deskphone software version of the
set:
1. Sets having a software version prior to 3.5.0.8 must be upgraded to the intermediate version 3.5.0.8
2. Sets are upgraded to version R120-v3.6.0.5
• The OXO Connect must be operational
• A free IP address must be available for the set
Chapter
4
Installation and Cabling
3EH21123USAA - Ed. 01 - April 2017 - Installation Manual 73/207
