Page #130 background imageLoading...
Page #130 background image
9 1912.896 1912.896
Note:
By default, all frequencies used
Value sent to IBS: 0x3FF
0000 0011 1111 1111
table 4.10: RF Band US
Channel TX Freq RX Freq
3 1928.448 1929.312
4 1926.720 1927.584
5 1924.992 1925.856
6 1923.264 1924.128
7 1921.536 1922.400
Note:
By default, only 5 frequencies used
Value sent to IBS: 0x03E0
0000 0011 1110 0000
table 4.11: RF Band PWT
Channel Center Freq
0 1929.375
1 1928.125
2 1926.875
3 1925.625
4 1924.375
5 1923.125
6 1921.875
7 1920.625
Note:
By default, 8 frequencies used
Value sent to IBS: 0x03FC
Chapter
4
Installation and Cabling
3EH21123USAA - Ed. 01 - April 2017 - Installation Manual 130/207
