Note:
The Mini-MIX daughter board requires BACKXS-N back panel and PSXS-N power supply module. The Mini-MIX
daughter board can be used only in an OXO Connect Compact.
ARMADA VoIP32 or
ARMADA VoIP64
(optional)
HSL1/HSL2
(optional)
AFU
(optional)
DDR2 Module
(underneath)
Mini-MIX
(optional)
HSL and Mini-MIX
daughter boards
are not compatible
Mass Storage Daughter Board
(MSDB) 8 GB equipped with eMMC
(embedded Multi-Media Card)
Figure 2.2: Example of Daughter Boards on PowerCPU EE board
2.4.2.11 Provision By Platform
2.4.2.11.1 OXO Connect Compact
Chapter
2
Hardware: Platform and Interfaces
3EH21123USAA - Ed. 01 - April 2017 - Installation Manual 30/207
