Alcatel Vacuum Technology France --- IPUP A100 Instruction manual
Positioning the pump in the
pumping installation
Upper pump frame
Lower pump cover
4 tapped holes M10
for stackable frame or specific fixation system
(anti earthquake)
3 M8 Chc screw
Lower pump
Upper pump
Upper pump frame
Lower pump cover
Note :All handling devices are designed for handling one pump only.
