8.3 Forward / Reverse Rotational Selector (See Fig. D1, D2)
For drilling and screw driving use the forward rotation marked
“ ” (forward/reverse rotating control (4) is moved to the right
when looking at the drill from the front) (See D1). Only use reverse
rotation marked “ ” (forward/reverse rotating control (4) is
moved to the left when looking at the drill from the front) (See D2)
to remove screws or releasing a jammed drill bit.
WARNING: Never change the direction of rotation when
the chuck is rotating, wait until it has stopped!
8.4 Two-Speed Gear Selector (3) (See Fig. E)
The two-speed gearbox allows you to select a gear with the
optimum speed and torque to suit the application.
NOTE: When changing the two speed high / low gear selector (3),
ensure the drill/driver is not operating.
1. To select the LOW gear (low speed, high torque setting), push the
two-speed gear selector (3) backward,towards the back of the drill/
driver. The number “1” will be displayed.
2. To select the HIGH gear (high speed, low torque setting), push the
two-speed gear selector (3) towards the chuck.The number “2” will
be displayed.
Gear 1
Low speed range: for screwdriving or working with large drilling
diameter
D1 D2
