8028 SIP Doorphone (G2) FW 3.2
RTCP Port Selection
Select the port on which RTCP packets will be sent or received. If using the 'Next Higher
Port' option, ensure that the default multicast zone definitions are modified such that
zones are only assigned to even-numbered ports, leaving the next higher odd-numbered
ports free for RTCP packets.
Zone Definition
The “Expanded” Slave zones can be enabled/disabled in Basic Settings > Multicast.
Default IP addresses and ports may be revised for any given zone in the table.
Important: Ensure that the Address and Port settings are the same for all master and
slave devices.
Answer Tone and Page Volume
When an Algo device is the multicast Master, a page tone will play on the Slave device, so
it is recommended to set the Slave tone to “None”. If a page is received from a non-Algo
device that doesn’t send a tone, a tone can be inserted on the Slave device allowing for a
page tone to be played prior to page audio starting.
By default, the same page volume can be set for all Slave zones in the Basic Settings >
Features tab. Unique page volumes may be revised on a per-zone basis in the table
above. For instance, emergency pages can be louder on certain Slave endpoints.
Polycom Slave Tones
A tone may be set for any of the 25 Polycom Groups. If using an Algo device as a
Multicast master, it is recommended to set the slave tones to “None” to avoid conflicts, as
the Algo devices already multicast a tone by default.
These settings are available only if the 8028 is set as a Multicast Slave and “Polycom
Group Page” or “Polycom Push-to-Talk” are selected in the Basic Settings > Multicast tab.
Document 90-00104
05/21/2020
Page 48
