8028 SIP Doorphone (G2) FW 3.2
Setup and Installation
Getting Started - Quick Install & Test
This guide provides important safety information which should be read thoroughly
before permanently installing the product. Earth grounding is required for
installations with door station wiring that leaves the perimeter of a building
due to the potential for over-voltage fault conditions.
Note that this requirement does not apply when a door station is installed
indoors or on the outside wall of a building if the wiring runs directly into
the building.
1. If earth grounding is required (read safety caution above) then make that connection first
before connecting the control unit to the network or door station.
2. Flush or surface-mount the Digital Door Station at desired location and connect the
“CTRL” terminals of the Door Station to the Control Unit pluggable terminal block
positions indicated by the door station icon ( ). Note that a yellow caution sticker must
first be removed from the Control Unit pluggable terminal socket.
3. Connect the 8028 (G2) Control Unit to a network port. If the network switch supports
PoE (IEEE 802.3af 15W) or PoE+ (IEEE 802.3at 30W) then the control unit will power
up as indicated by the blue power light on the front. If the network switch does not
provide PoE then a PoE injector may be used or the optional Algo 75-00004 24Vdc
Power Adapter.
4. The red LED illuminated call button on the front of Door Station will turn on. After about
30 seconds, a beep will signal the completion of the boot process.
5. After the boot is complete, press the call button on the Door Station to hear the IP
address. (Once the SIP Server field is populated in the 8028 web interface, the call
button will contact the preconfigured extension when pressed.) The IP address may also
be discovered by momentarily pushing the reset button next to the RJ45 jack or
downloading the Algo locator tool to find Algo devices on your network:
www.algosolutions.com/locator
6. Access the 8028 SIP Doorphone web page by entering the IP address into a browser
(Chrome, Firefox or Edge) and login using the default password algo .
7. Enter the IP address or the name for the SIP server into the SIP Domain field under the
BASIC SETTINGS > SIP tab.
8. Enter the SIP Extension, Authentication ID, and Password. Also enter the target Dialing
Extension that the Intercom will call.
Note: The Authentication ID may also be called Username for some SIP servers, and in
some cases may be the same as the SIP extension.
Document 90-00104
05/21/2020
Page 10
