Removing the touch pad
WARNING: Before working inside your computer, read the safety information that shipped with your computer and
follow the steps in Before Working Inside Your Computer. After working inside your computer, follow the
instructions in
After Working Inside Your Computer. For more safety best practices, see the Regulatory Compliance
home page at dell.com/regulatory_compliance.
Prerequisites
1 Remove the base panel.
2 Follow the procedure from step 1 to step 5 in “Removing the solid-state drive”.
3 Follow the procedure from step 1 to step 8 in “Removing the palm rest”.
Procedure
1 Lift the connector latch and disconnect the touchpad cable from the touchpad.
2 Remove the screws that secure the touchpad to the palm-rest assembly.
3 Lift the touchpad o the palm-rest assembly.
1 screws (4) 2 touchpad cable
3 touchpad
28
